The outcomes obtained in laboratory assessments, using scintillator bars learn by silicon photomultipliers are reported. The present strategy is step one for ItagPro designing a precision monitoring system to be placed inside a free magnetized volume for the charge identification of low power crossing particles. The devised system is demonstrated ready to provide a spatial decision higher than 2 mm. Scintillators, Photon Solid State detector, particle monitoring units. Among the planned activities was the construction of a mild spectrometer seated in a 20-30 m3 magnetized air quantity, the Air Core Magnet (ACM). The entire design must be optimised for the dedication of the momentum and charge of muons within the 0.5 - 5 GeV/c range (the mis-identification is required to be lower than 3% at 0.5 GeV/c). 1.5 mm is required inside the magnetized air volume. On this paper we report the results obtained with a small array of triangular scintillator bars coupled to silicon photomultiplier (SiPM) with wavelength shifter (WLS) fibers.

This bar profile is right here demonstrated ready to offer the necessary spatial decision in reconstructing the place of the crossing particle by profiting of the charge-sharing between adjoining bars readout in analog mode. SiPMs are glorious candidates in replacing normal photomultipliers in many experimental conditions. Tests have been performed with laser beam pulses and radioactive source with a view to characterize the scintillator bar response and SiPM behaviour. Here we briefly current the observed behaviour of the SiPM utilized in our exams concerning the principle sources of noise and iTagPro shop the effect of temperature on its response and linearity. Several models and packaging have been considered. The main supply of noise which limits the SiPM’s single photon decision is the "dark current" charge. It's originated by charge carriers thermally created in the delicate quantity and current within the conduction band and subsequently it will depend on the temperature. The dependence of the darkish present single pixel fee as a function of the temperature has been investigated using Peltier cells so as to alter and keep the temperature controlled.

Dark present price depends also on the Vwk as proven in Fig. 3. As a way to have low rates of dark current the value of Vbias has been fixed at 1.5 V giving a working voltage Vwk of 29 V. It is clear that, iTagPro smart tracker if needed, ItagPro it may be handy to make use of a bias voltage regulator which robotically compensates for temperature variations. Not at all times the pixels of the SiPM work independently from one another. Photoelectrons (p.e.) can migrate from the hit pixel to another not directly fired by a photon. Optical cross-discuss between pixels results in a non-Poissonian behaviour of the distribution of fired pixels. An estimate of the optical cross speak chance can be obtained by the ratio double-to-single pulse fee as a function of the temperature. The probability depends weakly on the temperature and iTagPro support the measured level of cross-talk (15-16%) is suitable with the one reported within the datasheet. SiPM response as soon as its fundamental parameters and cells configuration are given.

Within the Fig. 4 it is shown the pulse peak distribution of the darkish present for the SiPM below take a look at. 0.2) mm diameter gap used to lodge a fiber to collect the light. The lateral floor of the scintillator strips is painted with white EJ-510 TiO2 Eljen paint. The scintillation mild is collected with 1.2 mm BCF-91A WaveLength Shifter (WLS) fiber produced by the Saint-Gobain Ltd. The WLS is glued into the opening working along the bar and its ends are polished. The read-out is carried out by the SiPM solely at one end and iTagPro device the opposite aspect is mirrored with reflecting tape to maximize the light collection. The entrance-end board prototype dedicated to the amplification and SiPM readout has been developed by the Bologna INFN electronic group. The current from the SiPM is discharged on the low enter resistance of the transimpedance amplifier; this provides small time constants, that is, quick signal rise time (using the OPA 656N with a 500 MHz bandwidth we acquire alerts with 20-30 ns of rise time).
